To generate primary key using auto-generation strategy, id attribute in the entity must be of String type. In order to use Auto-generation strategy, set strategy to GenerationType.AUTO. (This is default in case you don't specify any strategy). Sep 04, 2017 Although not a very common mapping, you can map a composite identifier where one of the Primary Key columns is auto-generated. While for a SEQUENCE identifier, we can use the JPA specification, for IDENTITY, we need to use the Hibernate-specific @SQLInsert annotation. Nevertheless, this mapping is possible when using Hibernate. Oct 28, 2018 Note that for both types of composite ids, the primary key class can also contain @ManyToOne attributes. Hibernate also allows defining primary-keys made up of @ManyToOne associations combined with @Id annotation. In this case, the entity class should also fulfill the conditions of a primary-key class. How to fetch the dropdown values from database and display in jsp: Dynamically Fetch data from Mysql to (drop down) select option in Jsp. This post illustrates, to fetch the data from the mysql database and display in select option element in Jsp. You should know. AUTO INCREMENT Field. Auto-increment allows a unique number to be generated automatically when a new record is inserted into a table. Often this is the primary key field that we would like to be created automatically every time a new record is inserted.
AUTO INCREMENT Field
Auto-increment allows a unique number to be generated automatically when a new record is inserted into a table.
Often this is the primary key field that we would like to be created automatically every time a new record is inserted.
Syntax for MySQL
The following SQL statement defines the 'Personid' column to be an auto-increment primary key field in the 'Persons' table:
Personid int NOT NULL AUTO_INCREMENT,
LastName varchar(255) NOT NULL,
FirstName varchar(255),
Age int,
PRIMARY KEY (Personid)
);
MySQL uses the AUTO_INCREMENT keyword to perform an auto-increment feature.
By default, the starting value for AUTO_INCREMENT is 1, and it will increment by 1 for each new record.
To let the AUTO_INCREMENT sequence start with another value, use the following SQL statement:
To insert a new record into the 'Persons' table, we will NOT have to specify a value for the 'Personid' column (a unique value will be added automatically):
VALUES ('Lars','Monsen');
The SQL statement above would insert a new record into the 'Persons' table. The 'Personid' column would be assigned a unique value. The 'FirstName' column would be set to 'Lars' and the 'LastName' column would be set to 'Monsen'.
Foreign Key
Syntax for SQL Server
The following SQL statement defines the 'Personid' column to be an auto-increment primary key field in the 'Persons' table:
Personid int IDENTITY(1,1) PRIMARY KEY,
LastName varchar(255) NOT NULL,
FirstName varchar(255),
Age int
);
The MS SQL Server uses the IDENTITY keyword to perform an auto-increment feature.
In the example above, the starting value for IDENTITY is 1, and it will increment by 1 for each new record.
Tip: To specify that the 'Personid' column should start at value 10 and increment by 5, change it to IDENTITY(10,5).
To insert a new record into the 'Persons' table, we will NOT have to specify a value for the 'Personid' column (a unique value will be added automatically):
VALUES ('Lars','Monsen');
The SQL statement above would insert a new record into the 'Persons' table. The 'Personid' column would be assigned a unique value. The 'FirstName' column would be set to 'Lars' and the 'LastName' column would be set to 'Monsen'.
Syntax for Access
The following SQL statement defines the 'Personid' column to be an auto-increment primary key field in the 'Persons' table:
Personid AUTOINCREMENT PRIMARY KEY,
LastName varchar(255) NOT NULL,
FirstName varchar(255),
Age int
);
The MS Access uses the AUTOINCREMENT keyword to perform an auto-increment feature.
By default, the starting value for AUTOINCREMENT is 1, and it will increment by 1 for each new record.
Tip: To specify that the 'Personid' column should start at value 10 and increment by 5, change the autoincrement to AUTOINCREMENT(10,5).
Auto Generated Primary Key Jpa
To insert a new record into the 'Persons' table, we will NOT have to specify a value for the 'Personid' column (a unique value will be added automatically):
VALUES ('Lars','Monsen');
The SQL statement above would insert a new record into the 'Persons' table. The 'Personid' column would be assigned a unique value. The 'FirstName' column would be set to 'Lars' and the 'LastName' column would be set to 'Monsen'.
Syntax for Oracle
In Oracle the code is a little bit more tricky.
You will have to create an auto-increment field with the sequence object (this object generates a number sequence).
Use the following CREATE SEQUENCE syntax:
MINVALUE 1
START WITH 1
INCREMENT BY 1
CACHE 10;
The code above creates a sequence object called seq_person, that starts with 1 and will increment by 1. It will also cache up to 10 values for performance. The cache option specifies how many sequence values will be stored in memory for faster access.
To insert a new record into the 'Persons' table, we will have to use the nextval function (this function retrieves the next value from seq_person sequence):
VALUES (seq_person.nextval,'Lars','Monsen');
The SQL statement above would insert a new record into the 'Persons' table. The 'Personid' column would be assigned the next number from the seq_person sequence. The 'FirstName' column would be set to 'Lars' and the 'LastName' column would be set to 'Monsen'.
Every JPA entity must have a primary key.
You can specify a primary key as a single primitive, or JDK object type entity field (see 'Configuring a JPA Entity Simple Primary Key Field').
You can specify a composite primary key made up of one or more primitive, or JDK object types using a separate composite primary key class (see 'Configuring a JPA Entity Composite Primary Key Class').
You can either assign primary key values yourself, or you can associate a primary key field with a primary key value generator (see 'Configuring JPA Entity Automatic Primary Key Generation').
Configuring a JPA Entity Simple Primary Key Field
The simplest primary key is one you specify as a single primitive or JDK object type entity field (see 'Using Annotations').
Note:
For a JPA entity primary key field code example, see:http://www.oracle.com/technology/tech/java/oc4j/ejb3/howtos-ejb3/howtoejb30mappingannotations/doc/how-to-ejb30-mapping-annotations.html#idUsing Annotations
Example 7-1 shows how to use the @Id annotation to specify an entity field as the primary key. In this example, primary key values are generated using a table generator (see 'Configuring JPA Entity Automatic Primary Key Generation').
Configuring a JPA Entity Composite Primary Key Class
A composite primary key is usually made up of two or more primitive or JDK object types. Composite primary keys typically arise when mapping from legacy databases when the database key is comprised of several columns. You can specify such a composite primary key with a separate composite primary key class (see 'Using Annotations')
A composite primary key class has the following characteristics:
All in one keylogger 3.9 serial key generator. It is a POJO class.
It must be public and must have a public no-argument constructor.
If you use property-based access, the properties of the primary key class must be public or protected.
It must be serializable.
It must define
equalsandhashCodemethods.The semantics of value equality for these methods must be consistent with the database equality for the database types to which the key is mapped.
You can make the composite primary key class either an embedded class owned by the entity class, or a nonembedded class whose fields you map to multiple fields or properties of the entity class. In the latter case, the names of primary key fields or properties in the composite primary key class and those of the entity class must correspond and their types must be the same.
Using Annotations
Example 7-2 shows a typical embeddable composite primary key class. Example 7-3 shows how to configure a JPA entity with this embedded composite primary key class using the @EmbeddedId annotation.
Example 7-2 Embeddable Composite Primary Key Class
Example 7-3 JPA Entity With an Embedded Composite Primary Key Class
Example 7-5 shows a nonembedded composite primary key class. In this class, fields empName and birthDay must correspond in name and type to properties in the entity class. Example 7-5 shows how to configure a JPA entity with this nonembedded composite primary key class using the @IdClass annotation. Because entity class fields empName and birthDay are used in the primary key, you must also annotate them using the @Id annotation.
Example 7-4 Non-Embedded Composite Primary Key Class
Example 7-5 JPA Entity With a Mapped Composite Primary Key Class
Configuring JPA Entity Automatic Primary Key Generation
Typically, you associate a primary key field (see 'Configuring a JPA Entity Simple Primary Key Field') with a primary key value generator so that when an entity instance is created, a new, unique primary key value is assigned automatically.
Table 7-2 lists the types of primary key value generators that you can define.
Table 7-2 JPA Entity Primary Key Value Generators
| Type | Description | For more information, see .. |
|---|---|---|
Generated Id Table | A database table that the container uses to store generated primary key values for entities. Typically shared by multiple entity types that use table-based primary key generation. Each entity type will typically use its own row in the table to generate the primary key values for that entity class. Primary key values are positive integers. | 'Table Sequencing' in the Oracle TopLink Developer's Guide |
Table Generator | A primary key generator, which you can reference by name, defined at one of the package, class, method, or field level. The level at which you define it will depend upon the desired visibility and sharing of the generator. No scoping or visibility rules are actually enforced. Oracle recommends that you define the generator at the level for which it will be used. This generator is based on a database table. | 'Table Sequencing' in the Oracle TopLink Developer's Guide |
Sequence Generator | A primary key generator which you can reference by name, defined at one of the package, class, method, or field level. The level, at which you define it, will depend upon the desired visibility and sharing of the generator. No scoping or visibility rules are actually enforced. Oracle recommends that you define the generator at the level for which it will be used. This generator is based on a sequence object that the database server provides. | 'Native Sequencing With an Oracle Database Platform' in the Oracle TopLink Developer's Guide 'Native Sequencing With a Non-Oracle Database Platform' in the Oracle TopLink Developer's Guide |
Note:
For an EJB 3.0 automatic primary key generation code example, see:http://www.oracle.com/technology/tech/java/oc4j/ejb3/howtos-ejb3/howtoejb30mappingannotations/doc/how-to-ejb30-mapping-annotations.html#sequencingUsing Annotations
Example 7-6 shows how to use the @TableGenerator annotation to specify a primary key value generator based on a database table. The TopLink JPA persistence provider will attempt to create this table at deployment time: if it cannot, then you must follow your database documentation to ensure that this table exists before deployment. When a new instance of Address is created, a new value for entity field id is obtained from ADDRESS_GENERATOR_TABLE. In this case, you must set the @GeneratedValue annotation attribute strategy to TABLE and generator to ADDRESS_TABLE_GENERATOR.
Example 7-6 GeneratedValue Strategy Table: @TableGenerator
Auto Generated Primary Key In Jpa 2018
Example 7-7 shows how to use the @SequenceGenerator annotation to specify a primary key value generator based on a sequence object provided by the database. The TopLink JPA persistence provider will attempt to create this object at deployment time: if it cannot, then you must follow your database documentation to ensure that this sequence object exists before deployment. When a new instance of Address is created, a new value for entity field id is obtained from database sequence object ADDRESS_SEQ. In this case, you must set the @GeneratedValue annotation attribute strategy to SEQUENCE and generator to ADDRESS_SEQUENCE_GENERATOR.
Example 7-7 GeneratedValue Strategy Sequence: @SequenceGenerator
Example 7-8 shows how to use the @GeneratedValue annotation to specify a primary key value generator based on a primary key identity column (autonumber column). When a new instance of Address is persisted, the database assigns a value to the identity column. In this case, the TopLink JPA persistence provider re-reads the inserted row and updates the in-memory Address entity to set id to this value.
